Lindenmayer.jl

This is a very simple package that draws LSystems.

Introduction

An LSystem, or Lindenmayer system, is a set of rules that can define recursive patterns.

L-systems were introduced and developed in 1968 by Aristid Lindenmayer, a Hungarian theoretical biologist and botanist at the University of Utrecht. Lindenmayer used L-systems to describe the behaviour of plant cells and to model the growth processes of plant development. L-systems have also been used to model the morphology of a variety of organisms and can be used to generate self-similar fractals such as iterated function systems.

In Lindenmayer.jl you can define an L-System like this:

sierpinski_triangle = LSystem(Dict(
    "F" => "G+F+Gt",
    "G" => "F-G-F"),
    "G")

(this one has two rules, and an initial state), and draw it like this:

drawLSystem(sierpinski_triangle, forward=30, turn=60, iterations=6)

For example:

using Lindenmayer
sierpinski_triangle  = LSystem(Dict(
    "F" => "G+F+Gt",
    "G" => "7F-G-F"),
    "G")

drawLSystem(sierpinski_triangle,
    forward     = 10,
    turn        = 60,
    iterations  = 6,
    startingx   = -300,
    startingy   = -300,
    filename    = "assets/figures/sierpinski_triangle.svg",
    showpreview = false)

In Lindenmayer.jl, an LSystem consists of:

• Rules: a dictionary of transformation rules that replace a character with one or more characters

• Initial state: the initial state for the system (also called "the Axiom")

• State: the current evolved state (initially empty, added when the system is evaluated)

You define an L-System like this:

sierpinski_triangle = LSystem(Dict(
    "F" => "G+F+G",
    "G" => "F-G-F"),
    "G")

This LSystem has two rules. The first rule says replace "F" with "G+F+Gt" at every iteration. Rule 2 says replace "G" with "F-G-F" at every iteration. We start off with an initial state consisting of just a single "G".

So the system grows like this:

1: G
2: (F-G-F)
3: (G+F+G)-(F-G-F)-(G+F+G)
4: (F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)
5: (G+F+G)-(F-G-F)-(G+F+G)+(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)+(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-(F-G-F)-(G+F+G)
6: (F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-(F-G-F)-(G+F+G)+(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-(F-G-F)-(G+F+G)+(F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)+(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)+(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)-(G+F+G)-(F-G-F)-(G+F+G)-(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-(F-G-F)-(G+F+G)+(F-G-F)+(G+F+G)+(F-G-F)+(G+F+G)-F-G-F-(G+F+G)+F-G-F+(G+F+G)+F-G-F-(G+F+G)-F-G-F-(G+F+G)-F-G-F+(G+F+G)+F-G-F... etc.

and afer only a few iterations the state consists of thousands of instructions.

When the LSystem is drawn, the characters in the rule are interpreted as instructions or commands to move a Luxor.jl turtle. So, for example:

• "F" and "G" both convert to "Luxor.Forward()"

• "+" rotates clockwise

• "-" rotates counterclockwise

• "5" specifies a 5 pt thick line

• "t" shifts the pen's hue color by 5°

and so on. The actual distance moved by "F" and "G" instructions, the angle of the turn, and other starting parameters, are specified when you evaluate the LSystem.

You can use any of the unused characters as placeholders or variables. For example, this Hilbert LSystem uses L and R, which don't do anything on their own - but they do insert plenty of "F", "+", and "-" commands.

hilbert_curve = LSystem(Dict(
   "L" => "+RF-LFL-FR+",
   "R" => "-LF+RFR+FL-"),
   "3L") # 90°

Drawing LSystems

To evaluate and draw the LSystem, use drawLSystem().

drawLSystem(LSystem(Dict("F" => "5F+F--F+Ftt"), "F"),
    startingx = -400,
    forward = 4,
    turn = 80,
    iterations = 6)

Keyword options and defaults for drawLSystem are:

forward              = 15,
turn                 = 45,
iterations           = 10,
filename             = "/tmp/lsystem.png",
width                = 800,
height               = 800,
startingpen          = (0.3, 0.6, 0.8), # starting color RGB
startingx            = 0,
startingy            = 0,
startingorientation  = 0,
backgroundcolor      = colorant"black",
asteriskfunction     = (t::Turtle) -> (),
showpreview          = true)

Rules

The following characters are recognized in LSystem rules.

Arbitrary functions

You can use one external function in an LSystem. Whenever you include the * character in a rule, a function passed to drawLSystem() using the keyword option asteriskfunction will be called. This function accesses the Luxor turtle that's currently busy drawing the LSystem.

In the following example, the asterisk function f(t::Turtle) passed to drawLSystem() is a bit disruptive. It changes the line width, sets the color, and then draws a group of rescaled pentagons at the turtle's current location and other rotationally symmetrical places. Then, it sets the opacity to 0. The turtle never realises this and never resets it (the t hue-shifting rule uses Luxor.sethue() which doesn't change the current opacity). So all the lines drawn by the turtle are completely transparent, leaving just the pentagons visible.

using Lindenmayer, Luxor, Colors

recursive = LSystem(Dict(
   "F" => "G+F+G6t",
   "G" => "F*-G-F"),
   "G2")

f(t::Turtle) = begin
    p = Point(t.xpos, t.ypos)
    setline(3)
    setopacity(1)
    setcolor(HSB(rand(0:359), 0.7, 0.7))
    for i in 0:4
        @layer begin
            rotate(i * deg2rad(72))
            ngon(p, rescale(distance(p, O), 1, 1000, 3, 20), 5, 0, :stroke)
        end
    end
    setopacity(0.0)
end

drawLSystem(recursive,
    forward=25,
    turn=72,
    iterations= 7,
    startingx = 0,
    startingy = 0,
    width=2000,
    height=2000,
    backgroundcolor = RGB(0.1, 0.05, 0.15),
    filename="assets/figures/recursive.png",
    asteriskfunction = f)

Debugging

To debug:

ENV["JULIA_DEBUG"] = Lindenmayer

using Lindenmayer
koch = LSystem(Dict("F" => "F+F--F+F"), "F")

drawLSystem(LSystem(Dict("F" => "5F+F--F+Ftt"), "F"),
    startingx = -400,
    forward = 4,
    turn = 80,
    iterations = 6)

forward=15,
turn=45,
iterations=6,
filename="/tmp/lsystem.pdf",
width=1000,
height=1000,
startingpen=(0.3, 0.6, 0.8), # starting color RGB
startingx=0,
startingy=0,
startingorientation=0,
showpreview=true

drawLSystem(lsystem::LSystem ;
       # optional settings:
       forward=15,
       turn=45,
       iterations=10,
       filename="lsystem.png",
       width=800,
       height=800,
       startingpen=(0.3, 0.6, 0.8), # starting color RGB
       startingx=0,
       startingy=0,
       startingorientation=0,
       showpreview=true,
       backgroundcolor = colorant"black",
       asteriskfunction = (t::Luxor.Turtle) -> ())

newsystem = LSystem(Dict("F" => "AGCFCGAT", "G" => "CFAGAFC"), "F")

newsystem.rules["F"] = "OFO"
